360 Around View Monitoring System for Nissian Patrol 2023
Features
| Features 1.AHD 720P/1080P high resolution image output 2.Does not affect the appearance of the vehicle after installation 3.Waterproof grade: IP68 4.automatic calibration 5.Four wide-angle cameras provide a panoramic view around the vehicle with no blind spots 6.Super starry night vision function 7.If you have camera needs, we can provide customized services |
 |
- |
Specifications
| TV Mode | PAL/NTSC |
| Image Sensor | 1/2.8 inch |
| Operation voltage range | DC12V(7.5-16V) |
| Working Current | 94mA±10mA |
| Power Consumption | 1.128W DC12 V |
| Video Output | 1.3±0.2Vpp 75Ω |
| USEFUL PIXELS | 1920*1080 |
| Minimum Illumination | 0.01Lux |
| Wide Dynamic | 95dB |
| Signal to Noise ratio | 46dB |
| Resolution ratio | 720P/1080P |
| Gamma value | 0.45 |
| Lens angle | 200 degrees |
| Operation Humidity | 85 RH% |
| Operation Temperature | -40℃~ +85℃ |
| Storage Temperature | -40℃~+85℃ |
| Special function | Super starry night vision |
